The TA5 range by Ifor Williams offers various headroom options, accommodating diverse transport needs. Available with 4’, 6’, or 7’ headroom, the TA5 provides a well-ventilated and spacious environment, making it ideal for both short and long hauls.
The 4’ headroom TA5 is slightly wider than other models at 5’, with wider side vents and flaps for optimal airflow. This low-profile design minimizes wind resistance, ideal for extended travel, and supports a maximum gross weight of 2700kg. Available body lengths include 8’, 10’, and 12’ [1].
The 6’ and 7’ headroom TA5 trailers serve as an alternative to the larger TA510 or DP120 models, offering a narrower build suitable for rural tracks. Available in 8’, 10’, and 12’ lengths, the 8’ and 10’ models also carry up to 2700kg, while the 12’ heavy-duty version supports a maximum weight of 3500kg [3].
The TA5’s factory-fitted EasyLoad ramp and folding deck system simplifies upper-deck loading without needing manual handling of ramps. The deck system folds away, optimizing space for livestock, and can be quickly deployed or stowed within minutes without special tools [4].
Equipped with gas springs, the EasyLoad ramp allows for easy lifting and secure locking, requiring minimal effort from the operator. This system must be specified at the time of order [2].
The TA5 range offers flexibility, comfort, and practical features like the EasyLoad system, making it a top choice for reliable livestock transport. Please specify the EasyLoad ramp during ordering for optimal functionality.
Built to last
The galvanized steel chassis and drawbar offer unbeatable corrosion protection. Couple this with the high strength, impact-resistant aluminium side panels, these trailers will often outlast the vehicles that tow them. The distinctive steel roof channels on braked models give a strong and rigid frame. The flooring on these trailers comprises of thick pressure treated timber planking protected by 2mm thick slip resistant aluminium treadplate.
Stability when towing
All of our braked trailers feature the exclusive Ifor Williams beam axle and leaf spring suspension system which has been developed and refined for a safe and stable ride. Similar systems are widely used on commercial vehicles where performance under load is essential. Renowned for its durability and ease of maintenance the Ifor Williams beam axle system contributes significantly to the low depreciation of our trailers.
All sizes are available with either the standard ramp or with the EasyLoad ramp and folding deck system.
| Model | Tyres | Gross Weight | Unladen Weight | Internal Length | Internal Width | Overall Length | Overall Width |
|---|---|---|---|---|---|---|---|
| TA5 8’x4’ H/R | 165R13C | 2700kg | 610kg | 2.32m | 1.53m | 3.92m | 2.10m |
| TA5 10’x4’ H/R | 165R13C | 2700kg | 710kg | 3.12m | 1.53m | 4.60m | 2.10m |
| TA5 12’x4’ H/R | 165R13C | 2700kg | 790kg | 3.72m | 1.53m | 5.20m | 2.10m |
| TA5 8’x6’ H/R | 165R13C | 2700kg | 725kg | 2.32m | 1.53m | 3.92m | 2.10m |
| TA5 10’x6’ H/R | 175/75R16C | 2700kg | 875kg | 3.12m | 1.53m | 4.60m | 2.10m |
| TA5 10’x7’ H/R | 175/75R16C | 2700kg | 910kg | 3.12m | 1.53m | 4.60m | 2.10m |
| TA5HD 12’x6’ H/R | 175/75R16C | 3500kg | 1005kg | 3.72m | 1.53m | 5.20m | 2.10m |
| TA5HD 12’x6’ H/R | 6.50R16C | 3500kg | 1005kg | 3.72m | 1.53m | 5.20m | 2.10m |
| TA5HD 12’x7’ H/R | 175/75R16C | 3500kg | 1030kg | 3.72m | 1.53m | 5.20m | 2.10m |
| TA5HD 12’x7’ H/R | 6.50R16C | 3500kg | 1030kg | 3.72m | 1.53m | 5.20m | 2.10m |
Various options and accessories are available for your trailer. Some may need to be ordered with your trailer as a factory fit item, while others can be purchased at a later date. Please check with your distributor before ordering.
